GPRS produces precise 2D floor plan deliverables based on field-collected data, providing your project team with dependable documentation for planning, design, construction, and building management. Our drawings deliver the as-built data you need to make informed decisions, reduce risk, and keep your project on track.

‍
Architectural Floor Plans

☐ Floor Plan Package

Included:

• ☐ Administration (Understanding project scope.)
• ☐ Floors
• ☐ Walls
• ☐ Doors
• ☐ Windows
• ☐ Stairs, Elevators, Ramps
• ☐ Exposed Columns
• ☐ Bathroom and Kitchen Cores (Includes plumbing fixtures, countertops, and major appliances, i.e. oven, fridge, stove, and dishwasher represented. Placeholders only, no custom blocks.)
• ☐ Water, Electrical and Gas meters, Transformers, Electrical Panels (Main/sub panels only, not equipment specific panels.)
• ☐ Room Dimensions/Labels/Hatching

Extra:

• ☐ Radiators and Baseboard Heaters
• ☐ Floor Drains
• ☐ Window Heights
• ☐ Door and Header Heights
• ☐ Built in Upper Cabinets/Overhead Delineation (Does not include tenant specific racks or displays.)
• ☐ Cubicals and Furniture
• ☐ Electricals (Outlets, Switches, Telecommunications Data.)
• ☐ Fire, Life and Safety Equipment
• ☐ Evacuation Plan (Does not include QR code or evacution virtual walkthrough.)

‍

☐ RCP Package - Finished Ceiling, Exposed Requires Structural Package

• ☐ Ceiling with Height/Type
• ☐ Exposed Deck
• ☐ Exposed Beams
• ☐ Exposed Trusses (Basic webbing.)
• ☐ Ceiling-Mounted Devices (List items included.)

‍

☐ Designer Subpackage

• ☐ Crown Moldings 2" and Larger
• ☐ Vertical Portion of Soffits

‍

☐ Structural Subpackage - Exposed Ceiling

• ☐ Joists/Rafters
• ☐ Girders
• ☐ Bracing
• ☐ Purlins
• ☐ Truss Webbing

‍

☐ Building Services MEP

Included:

• ☐ Pipe 6” & Above (O.D.)
• ☐ Rigid Ducts 12" & Above (O.D.)
• ☐ Equipment – Footprints (Mech, HVAC and Electrical.)

Extra: Fire Protection Package

• ☐ Sprinkler Piping
• ☐ Sprinkler Heads

‍

☐ Exterior Elevation Package

• ☐ Exterior Walls
• ☐ Changes in Material
• ☐ Windows, Doors, Curtain Walls
• ☐ Porches, Decks, Loading Docks
• ☐ Roofs. Parapets, Canopies, Skylights as Visible
• ☐ Exterior Stairs to Grade

(Not including coursing/carved floriated details)

‍

☐ Designer Subpackage

• ☐ Gutters and Downspouts
• ☐ Roof Elements - Pipe Vents, Solar Panels, and Skylights
• ☐ Exterior Wall Mounted Lighting
• ☐ Small Wall Vents

‍

☐ Roof Plan Package

If exterior elevations are included this can be reduced 80% (Houses only)

• ☐ Deck
• ☐ Parapets
• ☐ Hatch, Access Ladders and Skylights
• ☐ Vent Pipes and Roof Drains
• ☐ MEP Equipment Blocked Out (Including Solar Panels.)
• ☐ Add MEP Subpackage for the Roof

‍

☐ Roof Slopes - Flat Roof Tapered Insulation
‍

☐ Section Package (Per Section) - Default is "As Built" or "True Geometry"

Included:

• ☐ Single-line section, does not show interior detail

Extra:

• ☐ Elevate beyond the section cut - Would need to be orthogonal - From Revit model 75% less - Needs  window and door  and ceiling heights

‍

☐ Interior Elevation Package (Per Room)

• ☐ Walls
• ☐ Windows, Doors, Curtain Walls
• ☐ Casework (Built-in cabinets, countertops, and bookshelf units blocked out.)
• ☐ Fireplaces
• ☐ Ceilings and Floors Delineated

‍

☐ Designer Subpackage (Per Room)

• ☐ Electrical
• ☐ Crown, Base Molding, Door and Window trim
• ☐ Shelving - Individual Shelves (Does not include tenant specific racks or displays.)
• ☐ Cabinet Door Swings

MEP Floor Plans

** Must Include Floor Plan Package

☐ Conceptual Package

• ☐ Pipe 2” & Above (O.D.)
• ☐ Conduit 2” & Above (O.D.)
• ☐ Rigid Ducts
• ☐ Equipment – Footprints (Mech, HVAC, and Electrical.)
• ☐ Cable Trays

‍

☐ Detailed Package

• Pipe 1” & Above (O.D.)
• Conduit 1” & Above (O.D.)
• Rigid Ducts
• Flexible Ducts
• Equipment (Mech, HVAC, and Electrical) at moderate level of detail
• Cable Trays
• Valves, Actuators, Diverters
• Pipe Flanges, Couplings, and Unions
• Mechanical Pumps and Motors

‍

☐ Construction Documentation Package

• ☐ Pipe 1” & Above (O.D.)
• ☐ Conduit 1” & Above (O.D.)
• ☐ Rigid Ducts
• ☐ Flexible Ducts
• ☐ Equipment (Mech, HVAC, Electrical at moderate level of detail.)
• ☐ Cable Trays
• ☐ Valves, Actuators, Diverters
• ☐ Pipe Flanges, Couplings, and Unions
• ☐ Mechanical Pumps and Motors
• ☐ Pipe Hangers and Supports
• ☐ Junction Boxes
• ☐ Electrical Devices (Detectors, alarms, speakers, cameras, and exit signs.)
• ☐ Specialty Equipment (Cranes and conveyors.)
• ☐ Fire Protection Pipes and Sprinklers

‍

Area Analysis

☐ Subdivision Package

• ☐ Divides Areas into Multiple Spaces/Tenants - Occupant Area
  ‍

☐ Full BOMA Package

• ☐ Includes Rentable Areas (When applicable.)
• ☐ Full Building Must Be Measured

  • 0-50k( 1-5 suites)
  • 0-50k (5-20 suites)
  • 50k-100k (2-5 suites)
  • 50k-100k( 5-20 suites)
  • 100k-500k (2-5 suites)
  • 100k- 500k (5-20 suites)

☐ LOD Subpackage

• ☐ Lease Outline Drawings / Lease Occupancy Drawings
• ☐ Requires one of the two packages above
• ☐ Equipment and mechanical units located per client request
• ☐ May also include a 3D virtual tour

‍

Site Plans

☐ Site Plan Package

• ☐ Decks, Patios, Stairs, and Fences (State type).
• ☐ Driveways, Ramps, Sidewalks, and Stairs
• ☐ Hardscaping (Such as retaining walls, gravel pathways, fountains, fire pits, pools, and built-in BBQ.)
• ☐ Light and Electrical Poles
• ☐ Any Tree (That is 6” or more in diameter, permitting reasons.)
• ☐ Bollards or Posts
• ☐ Fire Hydrants
• ☐ Curbs, Parking Stops

‍

☐ Designer Subpackage

• ☐ Parking Striping
• ☐ Major Drains, Sewers and Catch Basins
• ☐ Electrical Boxes and Transformers (May be in ground.)
• ☐ Propane Tanks, Water Storage Tanks
• ☐ Oil Tank Filler Ports
• ☐ Lids to Septic Tanks (If visible, manhole covers, job dependent.)
• ☐ Water and Other Utility Shut-Offs (Labeled as water, gas, etc.)

‍

☐ Topo Subpackage

• ☐ Need details

‍
